1

Model

SIPL9740

2

Temperature Range

Ambient to 350°C

3

Display

128 × 64 Graphical LCD

4

TFT Screen

High Resolution Camera for viewing capillaries

5

Resolution

0.1°C

6

Temperature Sensor

Grade “A” PT-100, Platinum Sensor

7

Sample Capacity

3+1 Samples (one 6mm provision) Test Tube, for the determination of Boiling Point of Any Liquid

8

Application Area

Miniature Furnace Module

9

Application

Suitable for Boiling & Melting Point

10

Temp. Control & Ramp Rate Heating

Microprocessor controlled closed loop PID, Auto/Adjustable Ramp Rate Heating 2°C to 10°C/minute by UP/DOWN keys, can be increased or decreased during running/operation

11

Melting View

Front & Rear Glare-free illumination and Large Magnifier for stain-free observation of melting operation. Melting/Boiling point reading is held by activating the “HOLD” key and reading is protected from power failure till “RESET” is activated

12

PC Interface

USB to PC

13

Power Supply

230 V ±10%, AC 50 Hz

14

Dimension

270 × 330 × 160 mm (L × B × H)

15

Weight

8.5 kg

16

Accessories

25 mm Screen, Melting Tubes – 100 pcs, boiling tubes – 05 Nos, Cleaning Wires, USB Data Cable, Software CD, Main Lead, Instruction Manual
